Forklift Booms - 6,000 lb. Capacity

Turn forklifts into mobile cranes to move large beams and lumber. Versatile.
  • Welded steel construction with powder-coat finish.
  • Telescopic pole with rigid and swivel hooks.
  • Hook can be moved along boom shaft.
  • Safety chain secures boom to forklift. Fork pockets on 24" centers.
  • Adjustable screw locks boom in any position.
*Single hook capacity decreases as distance between hook and forklift increases.
MODEL
NO.		 DESCRIPTION CAPACITY (LBS.) TELESCOPING
LENGTH		 FORK POCKETS
W x H		 WT.
(LBS.)		 PRICE
EACH		 IN STOCK
SHIPS TODAY
RETRACTED* EXTENDED
H-11666 Forklift Boom 6,000 1,800 36 to 144" 7 1/4 x 2 1/4" 395 $1,325  ADD
SHIPS VIA MOTOR FREIGHT
DIMENSIONS:
  • Telescoping Length: 84 - 154"
  • Extended: 153 3/4 x 9 1/2 x 32"
  • Retracted: 84 7/8 x 9 1/2 x 32"
  • Hook Point:
    • Minimum: 36"
    • Maximum: 144"
  • Safety Chain: 48"
  • Center of Gravity:
    • Vertical: 4 1/8"
    • Extended: 52 5/16"
    • Retracted: 34 5/8"
FEATURES:
  • (1) Rigid and (2) Swivel lifting hooks
  • Effective thickness less than 1".
  • Infinitely adjustable locking screw.
  • Lost Load: 390 lbs
CAPACITY:
DistanceMax Single Hook Capacity (lbs)
36"6,000
48"5,000
60"4,500
72"4,000
84"3,500
96"3,000
108"2,600
120"2,300
132"2,000
144"1,800
Ships Via Motor Freight
Availability: In Stock
Unit Weight: 525 lbs.
Instructions
Parts Diagram
Email Item
SPECIFICATIONSMETRICIMPERIAL
RETRACTED CAPACITY2,722 kg6,000 lbs.
EXTENDED CAPACITY817 kg1,800 lbs.
TELESCOPING LENGTH91 x 366 cm36 to 144"
FORK POCKETS W x H19 x 6 cm7 1/2 x 2 1/4"
WEIGHT179 kg395 lbs
