Uline Industrial Pallet Truck - Low Profile Fork, 48 x 27", Blue

Let your personal pallet truck stand out.
  • Slides into openings only 2" high.
  • Reinforced frame and bulkhead.
  • 3-position hand control - Raise, lower, neutral.
  • 2" lowered and 6.5" raised height.
  • 7" polyurethane steering wheels. 2" polyurethane fork wheels.
  • 205° steering arc.

    Pallet Truck Dimensions
MODEL
NO.		 DESCRIPTION FORK SIZE
L x W		 COLOR LOAD
CAPACITY		 WT.
(LBS.)		 PRICE EACH IN STOCK
SHIPS TODAY
1 3+
H-9612 Low Profile 48 x 27" Blue 4,400 lbs. 188 $600 $580  ADD
SHIPS ASSEMBLED VIA MOTOR FREIGHT
DIMENSIONS:
  • Overall: 64.5 x 47.4" (L x H)
  • Forks:
    • Width: 6.3"
    • Thickness: 1 1/2"
    • Distance Between Forks (Inside): 14.4"
TEMPERATURE:
  • -4° to 113° F
  • Hydraulic fluid may not function properly below 23° F.
FEATURES:
  • Non-marking wheels
INCLUDES:
  • Extra 3" Rod to lock hydraulics to change pump or handle.
REPLACEMENT WHEELS:
  • 7" Polyurethane Steering Wheel: H-5384
COMPATIBLE WHEELS:
  • 7" Nylon Steering Wheel: H-2186-310
VIDEO:
Ships Via Motor Freight
Availability: In Stock
Unit Weight: 203 lbs.
Instructions
Parts Diagram
Troubleshooting
Catalog Page 434
Email Item
SPECIFICATIONSMETRICIMPERIAL
FORK SIZE L x W122 x 69 cm48 x 27"
LOAD CAPACITY1,996 kg4,400 lbs.
WEIGHT85 kg188 lbs.
Ships Via Motor Freight
Availability: In Stock
Unit Weight: 203 lbs.
Instructions
Parts Diagram
Troubleshooting
Catalog Page 434
Email Item
PARTS:
  • H-2185-DR Dust Ring for Uline Pallet Trucks - 1 1/32"
  • H-2185-SEAL Y-Ring for Uline Stainless Steel Pallet Truck - 1”
  • H-2186-111 Stop Rubber for Uline Pallet Trucks
  • H-2186-314 Hydraulic Pump Retaining Ring for Uline Pallet Trucks
  • H-2186-315 Steering Bearing for Uline Pallet Trucks - 56.26 x 77.89 x 17.77mm
  • H-2186-337 Bearing Cover for Uline Pallet Trucks
  • H-2708-104 Adjusting Nut for Uline Pallet Trucks
  • H-2708-112 Elastic Pin for Uline Pallet Trucks - 1 1/8"
  • H-2708-317 Lever Plate Nut for Uline Pallet Trucks
  • H-2708-318 Lever Set Bolt for Uline Pallet Trucks
  • H-2708-AC101 Release Rod for Uline Pallet Trucks
  • H-2708-AC102 Chain and Adjusting Bolt for Uline Pallet Trucks
  • H-2708-AC105 Handle Axle for Uline Pallet Trucks
  • H-2708-AC106 Spring Pin for Uline Pallet Trucks - 1 1/3”
  • H-2708-AC107 Handle Shaft Bushing for Uline Pallet Trucks - 47/64 x 39/64"
  • H-2708-AC109 Handle Pressure Roller for Uline Pallet Trucks
  • H-2708-AC116 Elastic Pin for Uline Pallet Trucks - 33/64"
  • H-2708-AC117 Control Lever for Uline Pallet Trucks
  • H-2708-AC118 Roller for Uline Pallet Trucks
  • H-2708-AC121 Pull Board for Uline Pallet Trucks
  • H-2708-AC306 Dust Cover for Uline Pallet Trucks
  • H-2708-AC308 Steering Wheel Washer for Uline Pallet Trucks -1"
  • H-2708-AC321 Valve Cartridge for Uline Pallet Trucks
  • H-2900-113 Blade Spring for Uline Industrial Pallet Trucks
  • H-2900-114 Handle Spring for Uline Industrial Pallet Trucks
  • H-2900-115 Elastic Handle Pin for Uline Pallet Trucks - 1 3/16"
  • H-2900-302 Spring for Uline Pallet Trucks
  • H-2900-325 Seal for Uline Pallet Trucks
  • H-2900-326 O-Ring for Uline Pallet Trucks - 1 3/8”
  • H-2900-327 Dust Ring for Uline Pallet Trucks -1 43/64"
  • H-2900-328 Piston Rod for Uline Pallet Trucks - 10 15/16
  • H-2900-331 O-Ring for Uline Pallet Trucks - 9/16"
  • H-2900-LEVER Lever Plate for Uline Pallet Trucks - 2 x 2 3/4"
  • H-5384 Polyurethane Steering Wheel for Uline Pallet Trucks - 7 x 2"
Unable to find what you're looking for? Please contact us.
